Binocular Biological Microscope, BS-2022B

Be the first to review this product

R 9,615.68

Model: BS-2022B
Magnification: 40x-1000x
Eyepiece: WF10x
Objective: 4×, 10×, 40×, 100×(Oil)
Illumination: S-LED
Stage: 132×142mm/ 75×40mm
Viewing Head: Binocular
Focusing: Coaxial Coarse

Optional accessories are available for purchase separately. If you require a customised solution, please contact our technical specialists by selecting the "Add to enquiry" button and using our enquiry form or at sales@lasec.com.

Installation, training and special delivery requirements, such as the need for tail-lift trucks and additional labour and installation for large equipment and hazardous material (Hazmat) packaging, are chargeable in addition to standard freight and will be quoted separately before dispatch.

DISCLAIMER

All product images are for illustrative purposes only. Actual products may vary slightly in terms of colours, controls and visible features.

Online ordering is currently limited to South African customers, but our full range is still available. If you are ordering from outside South Africa, please log an enquiry or email internationallabsales@lasec.com, and our international sales team will gladly assist you through our traditional sales channels.

Availability:In stock

Only 2 left

SKU

IMICBS-2022

BrandBestScope

Skip to the end of the images gallery

Skip to the beginning of the images gallery

BS-2022B binocular biological microscope with dual eyepieces, rotating nosepiece, and mechanical stage.

stained cell structures in blue and red under brightfield microscopy.

stained tissue cross-sections in red viewed under brightfield microscopy.

Details

Product Overview

The BS-2022 series microscopes are economical, practical, and easy to operate. They feature energy-efficient LED illumination with a long service life, providing comfortable viewing conditions for extended observation.

These microscopes are widely used in educational, academic, and agricultural settings, as well as in research and study applications. With the use of a microscope adapter, a digital camera or digital eyepiece can be connected to either the trinocular tube or the eyepiece tube for image capture and documentation.

A rechargeable battery is available as an optional feature, allowing for outdoor use or operation in environments where the power supply is unstable.

Features

New machining process and advanced optical alignment technology
Comfortable operation with an updated, ergonomic design
Energy-efficient LED illumination with a long service life
Compact and flexible design, ideally suited for desktops and laboratory workbenches
Adjustable eyepoint height and interpupillary distance for personalised viewing comfort

Applications

The BS-2022 series microscopes are ideally suited for school-level biological education and basic medical analysis, providing reliable observation of a wide variety of prepared slides. They are widely used in clinics, hospitals, educational institutions, academic laboratories, and scientific research departments.

Technical Specifications

Item	Specification	BS-2022B
Viewing Head	Seidentopf Monocular Head, Inclined at 30°, 360° Rotatable
	Seidentopf Binocular Head, Inclined at 30°, 360° Rotatable, Interpupillary Distance 48-75mm	●
	Seidentopf Trinocular Head, Inclined at 30°, 360° Rotatable, Interpupillary Distance 48-75mm
	Seidentopf Binocular Head with 3.2MP digital camera, Inclined at 30°, 360° Rotatable, Interpupilary Distance 48-75mm, the software is ScopeImage 9.0
Eyepiece	WF10×/18mm	●
Eyepiece	WF16×/11mm	○
Objective	Achromatic Objective 4×, 10×, 40×, 100×(Oil)	●
	Plan Achromatic Objective 4×, 10×, 40×, 100×(Oil)	○
	Infinite Plan Achromatic Objective 4×, 10×, 20×, 40×, 60×, 100×(Oil)	○
Nosepiece	Backward Quadruple Nosepiece	●
Stage	Double Layer Mechanical Stage 132×142mm/ 75×40mm	●
Focusing	Coaxial Coarse & Fine Adjustment, Fine Division 0.002mm, Coarse Stroke 37.7mm per Rotation, Fine Stroke 0.2mm per Rotation, Moving Range 20mm	●
Condenser	Abbe NA 1.25 with Iris Diaphragm and Filter	●
Illumination	1W S-LED illumination, Brightness Adjustable	●
	12V/ 20W Halogen Lamp, Brightness Adjustable	○
	Kohler illumination	○
Optional Accessories	Phase Contrast Kit	○
	Dark Field Attachment	○
	Polarization Attachment	○
	Rechargeable battery	○
	Photo Adapter: used for Nikon or Canon DSLR camera	○
	Video Adapter: 1X or 0.5X C-mount adapter	○
Package	1pc/carton, 32cm26cm44cm, 6kg	●
Note: ● Standard Outfit, ○ Optional
