AC600 Series Ductless Chemical Workstation, Tall 32 Inch

AC600 Series Ductless Chemical Workstation, Tall 32 Inch

Enquire for Price
  • Clear polycarbonate shell for 360° visibility
  • Constant airflow control and monitoring
  • Real-time hydrocarbon gas detection
  • Featuring the AirSafe® Automatic Safety Controller
  • External Dimensions (mm): 813x635x1016 (WxDxH)
  • Internal Dimensions (mm): 787x584x737 (WxDxH)
Availability:On Request
SKU
IMSXAC632TAS220

The AC600 Series ductless chemical workstation is a low-cost operator protection product that protects the end user from toxic vapors, gases, fumes, and particulates. Smaller and more mobile than a standard ductless fume hood, AC600 Series ductless chemical workstations are the perfect solution for performing low-volume applications with known chemicals. These products come standard with the same advanced safety features and technology as larger AirClean® Systems ductless hoods: gas phase-bonded carbon filtration, real-time gas detection, and constant airflow control and monitoring.

AirSafe® Automatic Safety Controller

AirSafe provides a simple-to-use interface combined with powerful airflow control, filtration monitoring, and gas detection capabilities. A proprietary sensor is used to accurately monitor and display face velocity on the LCD display. Blowers can be controlled manually or in 'automatic' mode, where AirSafe automatically controls blower speed in order to maintain a user-set face velocity. A solid-state hydrocarbon gas detector is linked to the controller for monitoring filtration breakthroughs. Audible and visible alarms alert the user in the event of low airflow or a required filter replacement.


AirSafe® Automatic Safety Controller

Features

  • AirSafe automatic safety controller
  • Integral base with deep spill lip
  • No ductwork required
  • No installation required; it plugs directly into a standard 110V or 220V electrical outlet
  • Clear polycarbonate shell for 360° visibility
  • Extremely quiet operation < 49dBA
  • Available in standard-height or tall version
  • Constant monitoring of fume hood face velocity with variable airflow control to user preset value
  • Lab event timer
  • Gas phase bonded carbon filtration

Benefits

  • Filter safety lockout to ensure correct filter replacement
  • Shipped fully assembled
  • Electronic gas detection for real-time gas phase filter monitoring
  • Tested to UL 61010-1, CSA C22.2 No. 61010-1, and EN 61326-1
  • Brushless, sparkless blower is post-filter
  • The deep base effectively contains accidental spills
  • Filter and electronics are located above the workspace, eliminating the chance of a chemical spill entering these sensitive areas
  • A low airflow alarm warns the user both visually and audibly
  • Real-time monitoring of installed filtration bed
GENERAL SPECIFICATIONS
Base/Work SurfacePolypropylene - No Rust
WallsClear Polycarbonate
Front SashClear Polycarbonate
Head Assembly/Filtration HousingMolded ABS
ControlsAirSafeTM
Automatic Safety Controller
Face Velocity - VariableUser Defined; 0.3-0.5 (m/s)
LightingVapor-Proof Fluorescent*
BlowersVariable-Speed; Brushless-Sparkless
Lab Event TimerAdjustable Audible / Visual Timer
Low Airflow AlarmCustom Audible / Visible Alarm
Filter Monitoring PackageAudible / Visible Alarm
CertificationsUL, CSA and CE
DIMENSIONS
External Dimensions (mm)
Width at Base806
Max Width826
Depth at Base610
Max Depth641
Height1022
Internal Dimensions (mm)
Width794
Depth597
Height737
Sash Opening Dimensions (mm)
Width743
Height: Opening102
Height: Fold 1241
Height: Fold 2654
TECHNICAL SPECIFICATIONS
Voltage220V
Amps1.0A
Power220 W
Volume of Filtered Air11.3 CMM
Prefilters Required1
Primary Filtration Layer1 Carbon
Secondary Carbon Filtration LayerNA
Unit Weight**84 kg

*Fluorescent lighting is optional on 32” models and will add 70 mm external depth

**Unit weight is an approximation and does not include weight of installed filtration
