CFX Opus 96 Real-Time PCR System
Enquire for Price
96-well, 5-color plus FRET, network-connected real-time PCR detection system, includes CFX Opus 96 base unit, cables.
- Online ordering is currently limited to South African customers, but our full range is still available. If you are ordering from outside South Africa, please log an enquiry or email internationallabsales@lasec.com, and our international sales team will gladly assist you through our traditional sales channels.
Availability:On Request
SKU
IBRD12011319
BrandBio-Rad
CFX Opus is the newest real-time PCR system in Bio-Rad's robust CFX family. The CFX Opus 96 Real-Time PCR System can analyze 96 wells and offers a number of new features, including:
- More uniform thermal performance
- Expanded connectivity - Wi-Fi, Ethernet, and USB
- Cloud connectivity: Operate CFX Opus on our BR.io cloud platform or with desktop CFX Maestro Software
- Network storage drive access for excellent data management
- Shuttle optical system yields consistent optical measurements across your sample plate
Applications and Uses for the CFX Opus Real-Time PCR Systems
- Gene expression without requiring ROX
- End-point analysis for sequence detection
- Protein thermal shift assays
- Assay optimization with thermal gradient
| Thermal Cycler | |
|---|---|
| Maximum ramp rate, °C/sec | 5 |
| Average ramp rate, °C/sec | 3.3 |
| Heating and cooling method | Peltier |
| Lid, °C | 30–110 |
| Temperature | |
| Range, °C | 4–100 |
| Accuracy, °C | ±0.2 of programmed target at 90°C |
| Uniformity, °C | ±0.3 well-to-well after 10 sec of arrival at target |
| Gradient | |
| Operational range, °C | 30–100 |
| Programmable span, °C | 1–24 |
| Optical Detection | |
| Excitation | 6 filtered LEDs |
| Detection | 6 filtered photodiodes |
| Range of excitation wavelengths, nm | 450–684 |
| Range of emission wavelengths, nm | 510–730 |
| Sensitivity | Detects 1 copy of target sequence in human genomic DNA |
| Dynamic range | 10 orders of magnitude |
| Scan Time | |
| All channels, sec | 12 |
| FAM/SYBR® Green only, sec | |
| Software | |
| Operating system | Windows 10 |
| Multiplex analysis | Up to 5 targets per well |
| System | |
| Sample capacity, wells | 96 |
| Sample size, µl | 1–50 (10–50 recommended) |
| Communication interface | USB 2.0 |
| Electrical approvals | IEC, CE |
| Dimensions (W x D x H), cm/in | 33x56x36 / 13x22x14 |
| Weight, kg/lb | 22/48 |
| Brand | Bio-Rad |
|---|
