Binocular Stereo Microscope, BS-3010A
R 4,907.65
- Model: BS-3010A
- Magnification: 20×-80×
- Eyepiece: WF10×/20mm
- Objective: 2×, 4×
- Working Distance: 57mm
- Illumination: LED
- Viewing Head: Binocular
Optional accessories are available for purchase separately. If you require a customised solution, please contact our technical specialists by selecting the "Add to enquiry" button and using our enquiry form or at sales@lasec.com.
Installation, training and special delivery requirements, such as the need for tail-lift trucks and additional labour and installation for large equipment and hazardous material (Hazmat) packaging, are chargeable in addition to standard freight and will be quoted separately before dispatch.
- Online ordering is currently limited to South African customers, but our full range is still available. If you are ordering from outside South Africa, please log an enquiry or email internationallabsales@lasec.com, and our international sales team will gladly assist you through our traditional sales channels.
Availability:In stock
SKU
IMICBS-3010A
BrandBestScope
Product Overview
Stereo microscopes, also known as low-magnification or dissecting microscopes, provide upright, unreversed 3D images. The BS-3010 series stereo microscope delivers high-resolution, high-quality imaging, making it suitable for a wide range of applications. Optional eyepieces and objectives are available to extend the magnification range and working distance.
The BS-3010 is a smart and cost-effective stereo microscope. Optional cold light and ring light illumination can be selected to enhance viewing conditions. These microscopes are widely used in electronics manufacturing, educational laboratories, sculpture work, home applications, and similar fields.
Features
- Compact multi-lens stereo microscope with angled head. With 10X and 20X eyepieces, the total magnification range is 20X to 80X.
- Durable metal pillar stand with both top and bottom LED illumination.
- High quality, advanced functionality, and excellent cost performance.
- Ergonomic design with sharp image display, wide field of view, and user-friendly operation.
- An ideal instrument for academic, medical, and industrial applications.
Applications
The BS-3010 series stereo microscopes are widely used in circuit board repair and inspection, surface mount technology work, electronics inspection, coin collecting, gemology and gemstone setting, engraving, and the repair and inspection of small components.
| Item | Specification | BS-3010A | |
|---|---|---|---|
| Viewing Head | Binocular Viewing Head, 45° Inclined, Interpupilary Distance 55-75mm, Un-rotatable | ● | |
| Binocular Viewing Head, 45° Inclined, Interpupilary Distance 55-75mm, 360° Rotatable | |||
| Eyepiece | WF5×/20mm | ○ | |
| WF10×/20mm | ● | ||
| WF15×/15mm | ○ | ||
| WF20×/10mm | ● | ||
| Objective | 2×, 4× | ● | |
| 1×, 2× | ○ | ||
| 1×, 3× | ○ | ||
| Working Distance | 57mm | ● | |
| 76mm | |||
| Illumination | Transmitted halogen light 12V/ 10W | ○ | |
| Incident halogen light 12V/ 10W | ○ | ||
| Transmitted and Incident LED illumination | ● | ||
| Package | 4pcs/carton, 68cm*31cm*38cm, 16kg | ● | |
| Note: ● Standard Outfit, ○ Optional | |||
| Brand | BestScope |
|---|
